Technical Resources

Selection guides, an alloy and material reference, and the specific information we need in order to quote each product family. Written for engineers and buyers who have a decision to make before they can raise an enquiry — ungated, with no email address required to read any of it.

Selection guidesWear alloy referenceWhat to send us, by productNo gate, no form

01  /  Selection guides

The decisions that have to be made before an enquiry exists.

Most of what a buyer needs is not a catalogue. It is help choosing between two materials, or knowing which limit applies. These are the reference tables and design rules published across this site, indexed in one place.

Specifying FRP for smelter acid plants — lessons from PASARWhat an FRP survey at a copper smelter acid plant found — UV damage, burnt duct, split bolted seams, rigid pump lines — and the specification line each finding leads to.Case-based checklist · 9 specification itemsFluoropolymer selection — PTFE, PFA, FEP, PCTFE, PVDF, PPContinuous heat resistance, recommended service temperature, water absorption and brittle temperature for seven liner materials, with a note on where each one stops.Table · 7 materials · 6 propertiesLining processes and their real limitsIsostatic moulding, sheet lining, sheet bonding, wire-mesh winding and sprayed PFA, ETFE and ECTFE — maximum service temperature, vacuum capability, and where each is actually used.Table · 7 processesThe HG/T 20538 length rule for lined pipeWhy a steel PTFE-lined straight run is capped at 4 m below 100 °C, 3 m to 150 °C and 2 m to 180 °C — and what it tells you when somebody quotes a single 6 m spool for a hot line.Design limitWear part alloys for crushing and millingMn13Cr2 through Mn22Cr3, high-chrome white iron and TiC-inserted composites, the casting standards each is certified to, and the inspection that proves it.Alloys · standards · inspectionFRP resin, laminate and standardsResin systems against liquor and temperature, laminate schedules to ASTM D3299, D4097, BS 4994 and ASME RTP-1, and why the cure schedule matters as much as the resin.Standards · laminatePressure equipment code routesASME VIII Div.1, EN 13445 / PED and GB 150 — what each requires, what a U stamp does and does not tell you, and how the ITP gets agreed before the price.Codes · ITPSlurry pump duty and wear materialsRubber, polyurethane and high-chrome wet ends selected against particle size and impact angle — and why running off the best efficiency point destroys impellers faster than any material choice can fix.SelectionValve materials, testing and actuationAPI 598 shell and seat testing, API 607 fire-safe, ISO 15848 fugitive emission, PMI on trim as well as body, and sizing actuators on real break torque.Testing · materials

02  /  Materials reference

Wear parts — what goes where, and why.

Compiled from the parts we actually ship into mining and cement plants. Where a Chinese grade is given, the nearest ASTM equivalent is shown alongside it — they are close, not identical, and we will tell you when the difference matters.

ApplicationTypical materialNotes
Jaw plates — fixed, movable, swingSpecify the duty, drawing revision, material grade and acceptance tests for the item. Confirm dimensions and loads as part of the enquiry.Manganese work-hardens under impact, so it suits primary crushing. TiC inserts extend life where the feed is highly abrasive rather than simply hard.
Cone crusher mantles, bowl liners, concavesSpecify the duty, drawing revision, material grade and acceptance tests for the item. Confirm dimensions and loads as part of the enquiry.Chosen against your abrasion index rather than by default. Cast and heat-treated to certified chemistry, with the heat number stamped on the part.
Impact crusher blow bars and impact platesMartensitic steel · high-chrome iron · ceramic-inserted · TiC-insertedMartensitic where impact dominates, high-chrome where abrasion dominates, ceramic or TiC inserts where both do. The wrong choice here halves service life.
Bimetallic wear plates, chocky bars, CCO and overlay plateHigh-chrome on mild steel, vacuum-brazed · tungsten carbide · TiCFor chutes, hoppers, transfer points and liners rather than crushing chambers.
Ball, rod and SAG mill liners and shell linersMn steel · alloy steel · high-chrome · rubber · compositeA trade-off between wear life, mill weight and noise. Supplied match-marked to an installation sequence with a written re-torque schedule.
Grinding mediaAlloyed cast balls · forged ballsHardness and chemistry certified per heat, with the spectrometer report issued against the batch.
Conveyor idlers and pulleysSpecify the duty, drawing revision, material grade and acceptance tests for the item. Confirm dimensions and loads as part of the enquiry.Specify the duty, drawing revision, material grade and acceptance tests for the item. Confirm dimensions and loads as part of the enquiry.
Kiln, cooler and hot-gas castingsHeat-resistant alloysGrate plates, cooler castings, burner and hood components for cement and lime duty.

Casting standards: ASTM A128 (manganese), ASTM A532 (high-chrome white iron), AS 2027, GB/T 5680. Chemistry is spectrometer-tested per heat and the report carries the heat number stamped into the casting. Full detail on Crushing & Milling and Castings & Forgings.

03  /  Enquiry checklist

What we need, by product family.

A quotation is only as good as the information behind it. This is the minimum that lets us price properly instead of hedging — and the fastest way to get a real number rather than a placeholder.

Wear partsMachine make, model and equipment number · the worn part, or photographs with measurements at the points we specify · current wear life and change-out interval · feed abrasion index and particle size distribution
Castings & forgingsDrawing or the part itself · material specification and standard · NDT requirement and acceptance criteria · quantity and expected repeat interval
FRP equipmentLiquor, concentration and pH · operating and design temperature · basin, deck or structure survey for retrofit work · your house laminate specification if you have one
PTFE and lined equipmentFluid, concentration and trace contaminants · temperature range and maximum excursion · whether the line or vessel sees vacuum, and to what level · cleanliness grade if electronic or ultra-pure
Pressure equipmentMechanical data sheet or P&ID extract · code, class and jurisdiction · third-party involvement required · your inspection and test plan
Pumps & pipingFlow, head and NPSH available · solids concentration, specific gravity and particle size distribution · operating temperature and pH · line list or isometrics for a package
Valves & dampersTag list · face-to-face dimension and flange rating · body and trim materials · actuation, fail position and signal · testing and certification required
Separation equipmentProcess data sheet · basin or filter deck survey · underflow density and rake torque duty for thickeners · machine make and model where you are matching an existing unit
Anything at allIf you only have a photograph and a part number, send that. We will tell you what is still missing rather than guess and quote something that does not fit.

04  /  Documents

Available on request, from a person.

We do not put a form in front of a PDF to harvest an email address. Ask for what you need and a named engineer sends it, usually the same day — and you get someone who can answer a question about it rather than an automated download.

Product presentationsWear parts for mineral processing · spare parts for the cement industry · FRP scrubber and duct systems · FRP shut-off valves and dampers · steel tanks, piping and process equipment · pumps · water treatment equipment
Capability statementCompany, capability envelope, quality system, standards worked to, and named references — the document a procurement department asks for before adding a supplier.
Reference listNamed clients with the equipment supplied and the year, released with the customer’s permission for the specific project you are asking about.
Quality documentation samplesA redacted example of a manufacturing data book — material certificates, weld map, NDT reports, test records and photographic history — so you can see the standard before you order.

Still not sure which material is right?

Send the duty — the fluid, the temperature, the abrasion, the pressure — and we will tell you what we would specify and why, before you commit to anything.
